VlZtO VX32L HDTV10A User Manual
WIDE - This button cycles through the available screen formats. The options for SD (Standard Definition
4:3) are Normal, Zoom and Panoramic.. The options for HD (High Definition 16:9) and RGB PC are
Normal and Zoom.
SLEEP - This button allows the user to select the sleep options by
adjusting the timer for 30, 60, 90 or 120 minutes.
MTS - This button will select the MTS options of Stereo, SAP or Mono in
TV mode and alternate audio channels, where available, in DTV mode.
CC - This button will select the Closed Caption mode. The options are
OFF, CC1, CC2, CC3 or CC4.
TV - Press this button to select TV.
AV - Repeated pressing of this button with switch between AV-C
(Composite, yellow RCA) and AV-S (S-Video) inputs.
COMPONENT - Press this button to select the Component (YPbPr) input.
HDMI - Press this button to select the HDMI input.
ZOOM (- and +) - Use these buttons to increase or decrease the size of
the picture. Note that in the zoom mode parts of the picture will not be
visible because they extend beyond the edges of the screen.
FREEZE - Press this button to "Freeze-Frame" the current screen. Press
this button again the continue playing.
RGB - This button selects an RGB Analog component such as a PC.
PIP - Use this button to activate the Picture-In-Picture mode.
PIP CH (- and +) - These buttons are used to select the channels within
the PIP screen when DTV/TV is the PIP input selected.
AUDIO - Press this button to switch the audio from the main screen to the
sub-screen while in PIP mode.
PIP INPUT- Press the button to choose the PIP input. No :/°he TV mus
be in P mode [x_ lis b on o be uncliona ol addiliona iMx£ms ion
regarding he PP options see seclion 4.17.2 ....Piclule_ Piclule (PP)
Mode page 47
PIP SIZE - Press this button to select the size of the PIP screen from one
of the following: small, medium or large.
MODE - Use this button to change the picture mode from Custom,
Standard, Movie and Game.
SWAP - Used to swap the inputs from the main screen and the sub-screen
while in PIP mode.
Version 3/13/2007 11
www.VlZlO.com
