Overview
5
Specifications
Part No.: F1DS102J, F1DS104J
Power: 9V, 1.1A DC adapter with center pin-positive polarity
PCs Supported: 2 (F1DS102J), 4 (F1DS104J)
Console Keyboard: PS/2 & USB
Console Mouse: PS/2 & USB
Monitor Supported: VGA and SVGA MultiSync, LCD
Max Resolution: 2048x1536@85Hz
Audio Input/Output: 3.5mm jack
Microphone Input/Output: 3.5mm jack
VGA Port: 15-pin HDDB type
LED Indicators: 4 (F1DS102J), 8 (F1DS104J)
Enclosure: High-impact plastic
Dimensions: F1DS102J
12.5 (L) x 5.5 (W) x 5.5 (D) in.
(317.5 x 139.7 x 139.7mm)
F1DS104J
12.5 (L) x 5.5 (W) x 5.5 (D) in.
(317.5 x 139.7 x 139.7mm)
Weight: F1DS102J
1.48 lbs. (0.67kg)
F1DS104J
1.50 lbs. (0.68kg)
Operating Temp: 32° to 104° F (0° to 40° C)
Storage Temp: -4° to 140° F (-20° to 60° C)
Humidity: 0-80% RH, non-condensing
Warranty: 3 years
Note: Specifications are subject to change without notice.
