2
• 6-port FireWire Hub
• Optional Hub stand
• FireWire cable (6-pin to 6-pin)
• 12 volt, 1.25 Amp power supply
• User manual
Package Contents
Features
• Supports the Open Host Controller
Interface Standard (OHCI)
• Provides four 6-pin FireWire Ports
• Operates in Self-Powered or Bus-Powered modes
• Amber-colored LED indicates that the Hub is powered
• Green-colored LED indicates that a powered FireWire
device is attached to the Hub
• FireWire Port on front of hub allows easy access for
temporary connections
• Connector plate cover helps organize and manage
attached FireWire Cables
• Includes a FireWire repeater feature. Extend length of
FireWire chain by up to 15 feet (4.5 meters).
• Unique Docking Ring feature allows the user to put
together a modular system consisting of additional
F5U526 Hubs, and future Belkin FireWire products.
Technical Specifications
Transport Speeds Supported: 100/200/400Mbps
LEDs: Amber LED indicates self-
powered mode
Green LED indicates a
powered device is attached
to the Hub
Power Mode: Self- or bus-powered
Operation Temperature: 41° F – 104° F (5° C – 40° C)
Stock Temperature: -4° F – 219° F (-20° C – 60° C)
Enclosure: Polycarbonate
Weight: 5.57oz. (158g)
Power Supply: Input: 100-120V AC
Output: DC 12V–1.25A
(15W Max)
Power Supply Polarity:
3
En
