: Press to set or change the time of
: Press to set or clear the timer.
: Press to set a timed cook mode.
: Press to set the stop time in a
UPPER LOWER (Double ovens only)UPPER LOWER
select upper or lower oven before setting lights,
: Press to turn oven lights on or off.
: Press to increase the time in one of the above
functions by one minute at a time. Press and hold
to increase by 10 minutes at a time
: Press to decrease the time in one of the above
functions by one minute at a time. Press and hold
to increase by 10 minutes at a time.
: For single ovens, press and hold lock and +
buttons at same time to turn safety lock on or off.
For double ovens, press and hold + and - buttons
to turn safety lock on or off (use Upper Lower
button to select oven fi rst). This function locks the
oven door for safety purposes.
PREHEAT LIGHT (one for each oven)PREHEAT LIGHT
Green digits to left of display. Displays time
Red digits to right of display.
Displays the chosen temperature for the oven.
change oven temperature. When
selected, the default temperature is used.
One beep signals that the entry is
accepted, two beeps signals that the entry is
the control detects a problem in the oven or its
electronics. See Self Help section, page 19, for
has a default temperature that appears when
the temperature knob is turned to
default is the most common temperature for the
When activated, oven bakes
for 72 hours before shutting off automatically. The
mode is Sabbath compliant for religious faiths with
“no work” requirements on the Sabbath.
(double ovens only): Green icon
shows which oven is active.
Red icons display inside box icons.
Indicates that door is locked.
Indicates active functions
(steady) and functions awaiting user input
Figure 4: HBL503 Model Single Ovens
9
Figure 3: HBL504 and HBN54 Model Single Ovens
Figure 2: All Double Ovens
2 4
1
3
5 8
7
10
6
11
12
13
14
17
10
16
17
16
