REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
351700
K Included in Engine Gasket Set--Ref. No. 358A.
D Included in Carburetor Overhaul Kit--Ref. No. 121C or 121D.
z Included in Carburetor Gasket Set--Ref. No. 977.
∆ Included in Valve Gasket Set--Ref. No. 1095A.
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
0284--15 Assemblies include all parts shown in frames. 08/30/2007
15
94 842883 Kit--Idle Mixture
(Teikei)
94C D842870 Kit--Idle Mixture
(Nikki)
-- -- -- -- -- -- N o t e -- -- -- -- -- --
494923 Kit--
Idle Mixture
Used on Type No(s).
0045, 1045.
95B 690718 Screw
(Throttle Valve)
(Nikki)
-- -- -- -- -- -- N o t e -- -- -- -- -- --
690728 Screw
(Throttle Valve)
(Teikei)
97C 808719 Shaft--Throttle
98B 808177 Kit--Idle Speed
(Nikki)
-- -- -- -- -- -- N o t e -- -- -- -- -- --
809716 Kit--Idle Speed
(Teikei)
102B D693711 Gasket--Carburetor
Body
(Nikki)
-- -- -- -- -- -- N o t e -- -- -- -- -- --
809645 Gasket--
Carburetor Body
(Teikei)
104 690739 Pin--Float Hinge
(Teikei)
104A D690882 Pin--Float Hinge
(Nikki)
105 809759 Valve--Float Needle
(Teikei)
108B 690883 Valve--Choke
(Nikki)
-- -- -- -- -- -- N o t e -- -- -- -- -- --
809643 Valve--Choke
(Teikei)
109 809710 Shaft--Choke
(Teikei)
109B 808181 Shaft--Choke
117 D842070 Jet--Main
(Standard)(Teikei)
117D D690881 Jet--Main
(Standard)(Right)
(Nikki)
117E D690880 Jet--Main
(Standard)(Left)(Nikki)
118 806859 Jet--Main
(High Altitude)
(Right)(Nikki)
-- -- -- -- -- -- N o t e -- -- -- -- -- --
842432 Jet--Main
(High Altitude)
(5000 Ft.)
842433 Jet--Main
(High Altitude)
(6500 Ft.)
842434 Jet--Main
(High Altitude)
(9000 Ft.)
118A D808406 Jet--Main
(High Altitude)
(Left)(Nikki)
121C 842436 Kit--Carburetor
Overhaul
(Teikei)
121D 842871 Kit--Carburetor
Overhaul
(Nikki)
122 690870 Spacer--Carburetor
125C 842073 Carburetor
(Teikei)
130C 690884 Valve--Throttle
-- -- -- -- -- -- N o t e -- -- -- -- -- --
809642 Valve--Throttle
(Teikei)
131 809718 Kit--Throttle Shaft
(Teikei)
133B 808180 Float--Carburetor
(Nikki)
-- -- -- -- -- -- N o t e -- -- -- -- -- --
809637 Float--
Carburetor
(Teikei)
142C D690879 Nozzle--Carburetor
(Standard)(Nikki)
-- -- -- -- -- -- N o t e -- -- -- -- -- --
842069 Nozzle--
Carburetor
(Standard)(Teikei)
146 691639 Key--Timing
161A 690916 Base--Air Cleaner
(Metal)
163A K692087 Gasket--Air Cleaner
(UsedWithMetalAir
Cleaner Base)
165 693148 Nut
(Ring Gear)
185 690939 Nut
(Air Cleaner Base)
187 791766 Line--Fuel
(Molded)
187A 791745 Line--Fuel
(Cut To Required
Length)
187C 791801 Line--Fuel
(Molded)
188 692056 Screw
(Control Bracket)
192 807623 Adjuster--Rocker Arm
197 807163 Screw
(Back Plate)
202 690867 Link--Mechanical
Governor
203 690923 Crank--Bell
205 692083 Screw
(Bell Crank)
