Page 14 of 17 COLORbar™ SMD User Manual (Rev. 2)
(Standalone)
Set the product in one of the standalone modes to control without a DMX controller.
1. Connect the product to a suitable power outlet.
2. Turn the product on.
Never connect a product that is operating in any standalone mode (either Static,
Automatic, or Sound) to a DMX string connected to a DMX controller. Products in
standalone mode may transmit DMX signals that could interfere with
signals from the controller.
Static Color Mode
To enable the Static Color Mode, do the following:
1. Press <MENU> repeatedly until C-- shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to choose a color (C1-C7).
4. Press <ENTER>.
Automatic Mode
To enable the Automatic Mode, follow the instructions below:
1. Press <MENU> repeatedly until P-- shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to choose your auto program (P1-P7).
4. Press <ENTER>.
You can adjust the speed of the automatic program as well.
1. Press <MENU> repeatedly until S-- shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN>
to adjust the duration of each step of the automatic program
from S001 (slow) to S100 (fast).
4. Press <ENTER>.
Color Mode
To enable the Custom Static Color Mode, follow the instructions below:
1. Press <MENU> repeatedly until U-- shows on the display.
2. Press <ENTER>.
3. Press <UP> or <DOWN> to choose between colors (R--, G--, b--).
4. Press <ENTER>.
5. Press <UP> or <DOWN> to choose the intensity of the color (000-100).
6. Repeat the steps to mix additional colors to create the color you need.
