Removing and Replacing Parts : Dell Latitude C800/C805 Service Manual
3. Reinstall the 4-mm screw that secures the flex cable mounting bracket to the top
cover.
4. Starting on the left side, use a magnetic screwdriver to reinstall the six 3-mm screws
that secure the display panel in the top cover.
5. Reinstall the display flex cable strain-relief screw and reconnect the flex cable to the
graphics card.
6. Reinstall the display assembly bezel.
Removing the Display Latch
Removing the Display Latch
1. Remove the
hinge cover.
2. Detach the
display flex cable from the strain relief and the graphics card.
3. Remove the display assembly bezel.
