DS_S48SP3R310_05222008
4
ELECTRICAL CHARACTERISTICS CURVES
For Negative Remote On/Off Logic
Figure 4: Turn-on transient at full rated load current (5 ms/div).
Vin=48V. Top Trace: Vout, 1.0V/div; Bottom Trace: ON/OFF
input, 2V/div
Figure 5: Turn-on transient at zero load current (5 ms/div).
Vin=48V. Top Trace: Vout, 1.0V/div, Bottom Trace: ON/OFF
input, 2V/div
For Positive Remote On/Off Logic
Figure 6: Turn-on transient at full rated load current (5 ms/div).
Vin=48V. Top Trace: Vout, 1.0V/div; Bottom Trace: ON/OFF
input, 2V/div
Figure 7: Turn-on transient at zero load current (5 ms/div).
Vin=48V. Top Trace: Vout, 1.0V/div; Bottom Trace: ON/OFF
input, 2V/div
