100Mbps
On When the 100Mbps LED light is on, the respective port
is connected to a 100Mbps Fast Ethernet network.
Off When the respective port is connected to a 10Mbps
Ethernet or no link.
PoE
Green
Light
When the Green light is on, the respective port is
providing 48V of power.
Off When the light is off, either the respective port is
receiving power from an AC power source or no 802.3af
PD is found.
Red Light When the Red light is on, an error has occurred at the
respective port.
Option Ports 25~26 10/100/1000 Base-T / Mini-GBIC Status LEDs
FX Link
On When the FX Link LED light is on, the respective port is
connected to a 100 or 1000Mbps Gigabit Ethernet
network.
Off No link or linking to copper ports.
