SpecificationsDX-19E220A12
Specifications
Specifications are subject to change without notice.
Warranty
Dimensions and weight
Screen
Display resolutions/VGA scan rates
Tuner
Inputs
Outputs
Audio
Power
Miscellaneous
DX-19E220A12
Parts: 1 year
Labor: 1 year
DX-19E220A12
Without stand:
17.9 × 11.7 × 1.7 in.
(45.6 × 29.7 × 4.4 cm)
With stand:
17.9 × 13 × 5.4 in.
(45.6 × 33 × 13.8 cm)
Without stand:
5.9 lbs. (2.7 kg)
With stand:
6.4 lbs. (2.9 kg)
DX-19E220A12
Screen size measured diagonally 18.5"
Display type LCD
Panel 60 Hz vs.120 Hz 60Hz
Display resolution 720p
Panel resolution 1366 (H) × 768 (V)
Aspect ratio 16:9
Contrast ratio (typical)–panel 1000:1
Dynamic contrast ratio - list value 5000:1
Brightness (center typical) cd/m2 250 nits
Comb filter 3d y/c digital
Response time 5 ms
Horizontal viewing angle 170
Vertical viewing angle 160
DX-19E220A12
HDMI 1.4 Suggested Resolutions:
1080p, 1080i, 720p,
480p, 480i
HDMI 1.3 Suggested Resolutions:
1080p, 1080i, 720p,
480p, 480i
Component video Suggested Resolutions:
1080i, 720p, 480p, 480i
PC/VGA Suggested scan rates:
640 × 480/60Hz,
800 × 600/60Hz,
1024 × 768/60Hz,
1366 × 768/60Hz
DX-19E220A12
Analog NTSC
Digital ATSC, 8-VSB, Clear-QAM
DX-19E220A12
HDMI/DVI 1 (side)
E - E D ID c o m pl i a n t
HDCP compliant
HDMI with ARC
Component video 1 (back)
Composite video 1 (back)
Shared audio (component
and composite)
Yes
S-Video No
PC/VGA 1 (side)
3.5mm PC audio input 1 (side)
USB 1 (side) Supports JPEG
and firmware upgrade
DX-19E220A12
Video No
Analog audio 1 (side)
Digital audio No
WiFi No
Ethernet No
Headphone 1 (side)
DX-19E220A12
Simulated Surround Sound Yes
Sound Leveler Yes
Watts/Channel 2.3W x 2
Number of Speakers 2
DX-19E220A12
Power consumption On: 26 W
Standby: <1 W
Power input 120V/60Hz
DX-19E220A12
OSD languages English, French, Spanish
INlink No
Game Mode No
ENERGY STAR qualified Yes
Internet connectable No
TV base screws M4 type (14 mm length)
(4 pcs)
V-Chip (version 2.0) Yes
Sleep timer Yes
Channel labeling Yes
VESA mount (mm)
(horizontal × vertical)
100 × 100
Note
The length of the wall-mount screws vary depending
on the wall-mount bracket you purchased. See the
instructions that came with the wall-mount bracket
for screw lengths.
