Garmin G1000 Pilot’s Guide for Cessna Nav III 190-00362-03 Rev. Cviii
TABLE OF CONTENTS
8B.4 GDL 69/69A Weather and Digital Audio
Entertainment Interface 8B-17
Introduction ...............................................................8B-17
Radio IDs 8B-17
Activating XM Radio Services 8B-17
GDL 69 Weather Interface .......................................8B-19
Introduction ...............................................................8B-19
Displaying Weather Data on the Navigation
Map Page 8B-20
Navigation Map Page Weather Control Softkeys 8B-20
Navigation Map Setup Options 8B-22
Displaying Weather Data on the Nearest Pages 8B-23
Displaying METAR and TAF Information on the
Airport Information Page 8B-24
Displaying Weather Data on the AUX – Trip
Planning Page Map 8B-26
Displaying Weather Data on the Flight Plan Page
Maps 8B-26
Displaying Weather on the Weather Data Link Page 8B-27
Weather Data Link Page Softkeys 8B-28
NEXRAD Abnormalities 8B-28
NEXRAD Limitations 8B-28
NEXRAD Intensity 8B-28
Weather Data Link Page Setup 8B-34
Map Panning Information – Weather Data Link Page 8B-34
Weather Product Symbols 8B-36
Weather Product Age 8B-37
GDL 69A Interface – Digital Audio
Entertainment ............................................................8B-38
Introduction 8B-38
XM Information Page 8B-38
Data and Audio Radio ID 8B-39
Service Class 8B-39
Weather Products Window 8B-39
XM Radio Page 8B-40
XM Radio Interface Softkeys 8B-40
Active Channel 8B-40
Channels 8B-40
Volume 8B-41
Presets 8B-41
GDL 69 Troubleshooting 8B-42
9 – ANNUNCIATIONS AND ALERTS
9.1 Introduction 9-1
9.2 Alert Level Definitions 9-3
9.3 Cessna Nav III Aircraft Alerts 9-5
Voice Alerts 9-5
WARNING Alerts 9-5
CAUTION Alerts 9-5
CAUTION Alerts (T182, T206, and 206 with Prop
De-Ice Only) 9-5
Safe Operating Annunciation (T182, T206, and 206
with Prop De-Ice Only) 9-5
9.4 G1000 System Annunciations 9-7
9.5 G1000 System Message Advisories 9-11
MFD & PFD Message Advisories 9-11
Database Message Advisories 9-12
GMA 1347 Message Advisories 9-12
GIA 63 Message Advisories 9-13
GEA 71 Message Advisories 9-15
GTX 33 Message Advisories 9-15
GRS 77 Message Advisories 9-16
GMU 44 Message Advisories 9-16
GDL 69 Message Advisories 9-16
GDC 74A Message Advisories 9-17
Miscellaneous Message Advisories 9-17
APPENDICES
Appendix A: SD Card Use A-1
Aviation Database ...........................................................A-1
Terrain Database ..............................................................A-1
Appendix B: Abbreviations, Acronyms & NAV
Terms
B-1
Appendix C: Questions & Answers C-1
Appendix D: G1000 Map Datums D-1
