G4000 9'' x 19'' Lathe -7-
UUnnppaacckkiinngg
This Metal Lathe is shipped from the manufactur-
er in a carefully packed carton. If you discover the
machine is damaged after you’ve signed for deliv-
ery, and the truck and driver are gone, you will
need to file a freight claim with the carrier. Save
the containers and all packing materials for pos-
sible inspection by the carrier or its agent.
Without the packing materials, filing a freight
claim can be difficult. If you need assistance
determining whether you need to file a freight
claim, or with the procedure to file one, please
contact our Customer Service.
When you are completely satisfied with the con-
dition of your shipment, you should inventory its
parts.
The G4000 is a heavy machine (300 lbs. ship-
ping weight). DO NOT over-exert yourself
while unpacking or moving your machine – get
assistance. In the event that your Metal Lathe
must be moved up or down a flight of stairs, be
sure that the stairs are capable of supporting
the combined weight of people and the
machine.
SSeerriioouuss ppeerrssoonnaall iinnjjuurryy mmaayy
ooccccuurr..
PPiieeccee IInnvveennttoorryy
The Model G4000 is, for the most part, pre-
assembled at the factory. Inside the crate you’ll
find:
• The Model G4000 Metal Lathe
• 4" 3-jaw Chuck
• 7" 4-jaw Chuck
• Face Plate
• Steady Rest
• Following Rest
• 4-Way Tool Post
• C-Type Tool Post
• Toolbox
• Metric Allen
®
Wrenches
• 8-10mm Combination wrench
• Regular Screwdriver
• Phillips
®
Screwdriver
• Oil can
• 30T Gear (2)
• 36T Gear
• 42T Gear
• 45T Gear
• 80T Gear (2)
• Chuck wrenches (2)
• Chuck Removal Bars (2)
• Reverse Jaws for the 3-Jaw Chuck
• Dead Centers - MT #2, MT #3
• Live Center - MT #3
In the event that any non-proprietary parts are
missing (e.g. a nut or a washer), we would be
glad to replace them, or, for the sake of expedi-
ency, replacements can be obtained at your local
hardware store.
