Transmission
3
C450 3-27
–
Tone
When using a rotary dialing (pulse) telephone line, press [Tone] to
select push-button tone mode. This is used when using a fax infor-
mation service and so forth when [Tone] is selected. A “T” is dis-
played on the screen.
– In case of the dial (pulse) line, you can switch it to the push-button
tone using the asterisk [1] key.
–
Pause
Press [Pause] to insert a space in a dialed number. Pressing [Pause]
once creates an interval of one second between numbers. Multiple
spaces can also be entered. A “P” is displayed on the screen.
– When the PBX connection is ON and a call is made from the internal
line to the outside line, press [Pause] after the outside line number
such as “0” so that dialing is made more surely. “P” is displayed on
the screen.
–
-
This is entered as a separation symbol when dialing. It has no effect
on dialing. A “-” is displayed on the screen.
–
Abbr. dial
Enter the abbreviated dialing number (up to 2,000 from 0001 to
2000) through the keypad and specify the destination registered in
the address book.
On the screen, A abbr. number: Destination name is displayed as
seen in the example “A0001: KMBT”.
–
Scan to e-mail
An e-mail attached with an image is sent.
– When the destination is an e-mail address, the subject of the e-mail,
the text, the file name of image, and the from of the sender can be
set manually. For details, refer to “Setting transmission conditions”
on page 3-11.
– No sending or reception of a fax in color is available. If you want to
send an image in color, use the scan function. For more information
of the scan function, see “User's guide – Network scanner opera-
tions”.
–
Recently dialed #
A fax transmission is made to the destination to which transmission
was made previously.
– For details of Recently dial #, see “Manual redialing” on page 3-30
–
Save in user box
An image is saved in the internal hard disk.
3 Press [Start].
Transmission begins.
