Connections (Continued)
22
IEEE-1394 Connections
Connect the “IEEE-1394” jack from the compatible device to one of the “IEEE-1394” jacks on the HD DVR with an
IEEE-1394 cable.
Compatible IEEE-1394 devices
DVHS Maker Compatible Model
Victor HM-DH30000
Panasonic NV-DH1, NV-DH2
Hitachi DT-DR20000, DT-DRX100
Toshiba A-HD2000
JVC HM-DH30000U
Mitsubishi HV-HD1000
MV Camcorder Maker Compatible Model
Sony IP-7, IP-55, IP-220
otes
The HD DVR does not allow daisy-chaining of IEEE-1394 device.
Do not connect more than one IEEE-1394 devices of a kind. You can connect only one DVHS and one MV
Camcorder.
HD DVR Connection Panel
DVHS or MV Camcorder Connection Panel
Specify 6-pin connector
DV
IN/OUT
