Orbit 3 MICROBOARDS TECHNOLOGY, LLC
6
Installation Requirements
System Setup
• Connect the power cable to the Orbit 3 duplicator and plug in to a protected power outlet strip or UPS
power supply.
• Turn on power to the duplicator.
• Install the Input Rods and Output Bin. The system is now ready to use.
Install your Orbit 3 duplicator in the following environment:
9 On a level and stable surface
9 In a well ventilated location
9 Temperature: 40-100° F (5-40° C)
9 Humidity: 20-80%RH (no dew formation)
9 In an area with enough space to access the reject area behind the Orbit 3
9 In an area with enough vertical space for loading the Input bin
9 In an area with enough space for the Output Bin
Do not install your Orbit 3 duplicator in the following places:
8 Under direct sunlight (If the machine is exposed to sunlight, the light should be blocked by a curtain or
blind.)
8 A dusty location
8 A place where there is a lot of vibration
8 Near open flame
8 A place where the temperature and humidity change drastically
8 Near a heating device such as a heater or furnace
8 A location where air from an air conditioner blows directly onto the unit
8 Near a container filled with water
In winter during times of low humidity or in a location where static electricity is
generated, use an anti-static-electricity mat or humidifier to prevent static electricity.
Installing the Input Rods
The input rods should be installed onto the Orbit 3 before attempting to load the Input bin.
The short, wide rod is shipped in the correct location, in the far left Input rod position. The remaining 2 long
input rods should be installed on the right.
Power supply
Use house current as the power source for the unit.
Do not use an outlet near a motor driven appliance (i.e. air conditioner, copying machine).
Use an outlet with stable power supply voltages.
Do not overload an outlet. Do not use a service outlet from a PCs or other office machine.
Do not touch the power cord with a wet hand.
Be careful not to damage the power cord.
Inspect the power cord periodically.
In the event that the power cord is damaged, replace the power cord.
