En-54
Specifications
Amplifier Section
Video Section
Tuner Section
■ FM
■ AM
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Others
Specifications and features are subject to change without
notice.
Rated Output Power (North American)
80 watts minimum continuous power
per channel, 8 Ω loads, 2 channels
driven from 20 Hz to 20 kHz with a
maximum total harmonic distortion
of 0.08% (FTC)
100 watts minimum continuous
power per channel, 6 Ω loads, 2
channels driven at 1 kHz with a
maximum total harmonic distortion
of 0.1 % (FTC)
(European)
2 ch × 130 W at 6 Ω, 1 kHz, 1 ch driven
of 1 % (IEC)
Dynamic Power 180 W (3 Ω, Front)
160 W (4 Ω, Front)
100 W (8 Ω, Front)
THD +N
(Total Harmonic Distortion
+Noise)
0.08 % (20 Hz
–20 kHz, half power
)
Damping Factor 60 (1 kHz, 8 Ω)
Input Sensitivity and
Impedance
200 mV/ 47 kΩ (LINE)
2.5 mV/ 47 kΩ (PHONO MM)
Rated RCA Output Level
and Impedance
200 mV/ 2.2 kΩ (REC OUT)
Maximum RCA Output
Level and Impedance
2V/ 2.2kΩ (REC OUT)
Phono Overload 60 mV (MM, 1 kHz, 0.5 %)
Frequency Response 5 Hz–100 kHz/ +1 dB–3 dB
Tone Control
Characteristics
±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 106 dB (LINE, IHF-A)
80 dB (PHONO MM, IHF-A)
Speaker Impedance 4 Ω–16 Ω
Input Sensitivity/Output Level
and Impedance
1 Vp-p /75 Ω (Composite)
Tuning Frequency Range (North American)
87.5 MHz– 107.9 MHz
(European)
87.5 MHz– 108.0 MHz RDS
Tuning Frequency Range (North American)
530 kHz–1710 kHz
(European)
522/530 kHz–1611/1710 kHz
Preset Channel 40
Power Supply (North American)
AC 120 V, 60Hz
(European)
AC 230 V, 50Hz
Power Consumption (North American) 3.1 A
(European) 295 W
No-sound Power Consuption (North American) 55 W
(European) 45 W
Stand-by Power Consumption (North American) 0.2 W
(European) 0.3 W
Dimensions (W H D) 435 × 149.5 × 328 mm
(17-1/8" × 5-7/8" × 12-15/16")
Weight (North American)
8.6 kg (19 lbs.)
(European)
8.8 kg (19.4 lbs)
Composite BD/DVD, VCR/DVR, CBL/SAT,
GAME
Composite MONITOR OUT, VCR/DVR
Digital Inputs Optical: 2
Coaxial: 2
Analog Inputs PHONO, CD, TV/TAPE, GAME,
CBL/SAT, BD/DVD, VCR/DVR
Analog Outputs TV/TAPE, VCR/DVR
Pre Outputs L/R, SUBWOOFER, ZONE 2 L/R
Speaker Outputs SPEAKERS A
SPEAKERS B
Phones 1 (6.3 ø)
Ethernet 1
IR Input/Output 1/1
USB Front 1
Universal Port 1
1
