COMPONENT
VIDEO IN
DVD-Recorder
Y
P
P
B
R
COMPONENT VIDEO OUT
COMPONENT
VIDEO IN
DVD-Recorder
COMPONENT
VIDEO OUT
Y
P
P
B
R
COMPONENT VIDEO OUT
COMPONENT VIDEO OUT
Video cable
Audio cable
Y-
Blue
Red
Green
PB -
PR -
L - White
R - Red
Setup
TVAspect
Progressive
TV System
4:3
On
PAL
AV1 Output
Video
AV2 Settings
Tuning
Disc
Sound
Display
Connection
Others
VHS
SELECT
RETURN
ENTER
TAB
50
50
COMPONENT VIDEO OUT socket
The sockets can be used for INTERLACE or PROGRESSIVE output and deliver a
clearer picture than the S VIDEO OUT socket.
Connections via these sockets output the colour difference signals (P /P ) and the
brightness signal (Y) separately.
Colours can be reproduced true to the original colour.
The properties of the COMPONENT VIDEO input socket are dependent on the
TV or screen.
BR
!
!
!
Connect the COMPONENT VIDEO OUT sockets of the unit with the
COMPONENT VIDEO IN of the TV unit. Use a Video cable.
Always connect sockets with the same colour.
Connect the audio cables to the corresponding audio input sockets on the TV.
14
Connecting a TV with COMPONENT VIDEO input sockets
ENTER
ENTER
ENTER
ENTER
RETURN
Progressive television picture
If your TV with LCD or plasma screen supports the progressive process, connect it
to the COMPONENT VIDEO OUT sockets.
If you want to enjoy full progressive video, set Progressive to [On].
Press .
Select [To Others] with and confirm with .
Select [Setup] and confirm with .
Select [Connection] , [Progressive] with and confirm with .
Select the option [On] with and confirm with .
Press multiple times to return to the television picture.
If the AV1 Output setting in the Setup menu is set to [RGB 1/2 ( without component )],
there is no output to the COMPONENT VIDEO OUT sockets.
Set this option to [Video ( with component )].
If the unit is connected to the TV via the S VIDEO OUT or the AV1 socket,
output is Interlace regardless of the settings
The progressive picture aspect ratio (height to width) is set to 16:9. DVD-Video with
a of 16:9 is properly displayed. However, video material with an
image page ratio of 4:3 is shown stretched from right to left. If it is possible to adjust
the on your television, select the setting [Progressive - On].
With a normal television, the progressive output can cause the picture to flicker,
even if the television is progressive-compatible.
Select the setting [Progressive - Off].
FUNCTIONS
!
!
!
!
!
with
with ,
picture aspect ratio
picture aspect ratio
.
!
LCD/plasma television or LCD projector
If progressive output is used, videos can be viewed
in High Resolution, for example from DVD-Video.
COMPONENT VIDEO OUT on this unit is connected
with the COMPONENT VIDEO IN on the television.
Select the [Progressive - On] setting.
Progressive output
Conventional televisions
On a normal television, Progressive output can
cause flickering even if the television is
Progressive-compatible.
Select the [Progressive - Out] setting.
Progressive-compatible televisions (PAL)
Progressive output
COMPONENT
VIDEO OUT
COMPONENT
VIDEO OUT
AUDIO
L
R
OUT
S VIDEO
OUT
COMPONENT VIDEO OUT
Y
P
P
B
R
TV
YPPBR
COMPONENT
VIDEO IN
DIGITALAUDIO OUT
(PCM/BITSTREAM)
Audioinput L/R
