Setup
≥ Do not heat or expose to flame.
≥ Do not leave a battery pack in an automobile
exposed to direct sunlight for a long period of
time with doors and windows closed.
Notice about the rechargeable battery
The battery is designated recyclable.
Please follow your local recycling regulations.
The times shown in the tables below are for when the temperature is 25 oC and the humidity is 60%. If the
temperature is higher or lower than 25 oC, the charging time will become longer.
∫ Charging time
≥ The charging time shown in the table are approximations.
≥ “2 h 25 min” indicates 2 hours 25 minutes.
∫ Recordable time
≥ The actual recordable time refers to the recordable time when repeatedly starting/stopping recording,
turning the unit on/off, moving the zoom lever, etc.
≥ “2h5min” indicates 2hours 5 minutes.
≥ The display changes as the battery capacity reduces.
####.
If the battery discharges, then ( ) will flash.
≥ The recordable times will vary depending on the status of use. These times are approximations. The
recordable time will become shorter when you use this unit with the LCD monitor lit up by pressing the
POWER LCD PLUS button.
≥
The batteries heat up after use or charging. This unit will also heat up while being used. This is not a malfunction.
≥ Be aware that the operating time of the battery will become shorter in low temperatures. We recommend
charging a spare battery for use when recording.
CAUTION
Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type recommended by the
manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.
Charging time and recordable time
Battery model number Voltage/capacity Charging time
Supplied battery/
CGA-DU12 (optional)
7.2 V/1150 mAh 2 h 25 min
CGA-DU14 (optional) 7.2 V/1360 mAh 2 h 45 min
CGA-DU21 (optional) 7.2 V/2040 mAh 3 h 55 min
Battery model
number
Voltage/capacity
Recording
destination
Maximum continuously
recordable time
Actual recordable time
Supplied battery/
CGA-DU12
(optional)
7.2 V/1150 mAh
[HDD] 2h5min 55min
[SD] 2h20min 1h
CGA-DU14
(optional)
7.2 V/1360 mAh
[HDD] 2h30min 1h5min
[SD] 2h45min 1h15min
CGA-DU21
(optional)
7.2 V/2040 mAh
[HDD] 3h45min 1h40min
[SD] 4h10min 1h50min
