Specifications
74
Specifications
Power
Power rating AC 220 - 240 V, 50 / 60 Hz 0.57 A
Normal (Home) mode 69 W
Standby condition 0.24 W
Display
panel
Aspect Ratio 16:9
Visible screen size
80 cm (diagonal)
698 mm (W) × 393 mm (H)
Number of pixels 2,073,600 (1,920 (W) × 1,080 (H))
Sound
Speaker
(160 mm × 42 mm) × 2, 8
Audio Output 20 W (10 W + 10 W)
Headphones M3 (3.5 mm) stereo mini Jack × 1
PC signals
VGA, SVGA, WVGA, XGA
SXGA, WXGA ······ (compressed)
Horizontal scanning frequency 31 - 69 kHz
Vertical scanning frequency 59 - 86 Hz
Receiving Systems /
Band name
PAL B/G Reception of Off air broadcasts
Digital TV 8 MHz UHF (New Zealand) free-to-air TV broadcast reception
PAL 60 Hz
M.NTSC
NTSC
Playback of NTSC tape from some PAL Video recorders (VCR)
Playback from M. NTSC Video recorders (VCR)
Playback from NTSC Video recorders (VCR)
Aerial - Rear VHF / UHF
Operating Conditions
Temperature : 0 °C - 35 °C
Humidity : 20 % - 80 % RH (non-condensing)
Connection Terminals
AV1
Input
AUDIO L - R RCA PIN Type × 2 0.5 V[rms]
VIDEO RCA PIN Type × 1 1.0 V[p-p] (75
)
COMPONENT
Y 1.0 V[p-p] (including synchronisation)
P
B/CB, PR/CR ±0.35 V[p-p]
AV2
Input
AUDIO L - R RCA PIN Type × 2 0.5 V[rms]
VIDEO RCA PIN Type × 1 1.0 V[p-p] (75
)
AV3
Input
AUDIO L - R RCA PIN Type × 2 0.5 V[rms]
VIDEO RCA PIN Type × 1 1.0 V[p-p] (75
)
Audio
Output
AUDIO L - R RCA PIN Type × 2 0.5 V[rms] (high impedance)
Others
HDMI1 - 3
Input
TYPE A Connectors
•
This TV supports “HDAVI control 5” function.
PC Input
HIGH-DENSITY D-SUB 15PIN R / G / B: 0.7 V[p-p] (75
)
HD / VD: TTL Level 2.0 - 5.0 V[p-p] (high impedance)
DIGITAL
AUDIO OUT
PCM / Dolby Digital, Fiber optic
Card slot SD Card slot × 1
USB 1/2 USB 2.0 TYPE A Connectors DC 5 V, Max. 500 mA
ETHERNET 10BASE-T / 100BASE-TX
Dimensions (W × H × D)
779 mm × 531 mm × 207 mm (With Pedestal)
779 mm × 497 mm × 84 mm (TV only)
Mass
10.0 k
Net (With Pedestal)
9.0 k Net (TV only)
Note
●
Design and Specifications are subject to change without notice. Mass and Dimensions shown are
approximate.
