42PFL9732D/10
Specifications
Flat TV with Perfect Pixel HD Engine and Ambilight Surround
42" LCD integrated digital
Picture/Display
• Aspect ratio: 16:9
• Brightness: 550 cd/m²
• Contrast ratio (typical): 1200:1
• Dynamic screen contrast: 8000:1
• Response time (typical): Thr
ee (BEW equiv.) ms
• Viewing angle: 176º (H)/176º (V)
• Diagonal screen size: 42 inch / 107 cm
• Display screen type: LCD Full HD W-UXGA Act.
mat
rix
• Panel resolution: 1920 x 1080p
• Colour processing: 4 trillion colours (14-bit RGB)
• Picture enhancement: Perfect Pixel HD Engine, HD
Natu
ral Motion, Dynamic contrast enhancement,
1080p 50/60 Hz processing, 1080p 24/25/30 Hz
pro
cessing, 3/2 - 2/2 motion pull down, 3D
Combfilter, Active Control + Light sensor, Jagged
Line Suppression, Progressive Scan, Pulse Killer
Chip, Widescreen Plus, 100 Hz Clear LCD, Double
frame rate
• Screen enhancement: Anti-Reflection coated
sc
reen
Ambilight
• Ambilight Features: Ambilight Surround, Auto
adaptive to video content, Full operation in stand-
by, Efficient low energy lamp
• Ambilight light system: LED-wide colour
• Dimming Function: Manual and via Light Sensor
Supported Display Resolution
• Computer formats
Resolution Refresh rate
640 x 480 60 Hz
800 x 600 60 Hz
1024 x 768 60 Hz
1280 x 768 60 Hz
1360 x 768 60 Hz
1920 x 1080i 60 Hz
1920 x 1080p 60 Hz
• Vi
deo formats
Resolution Refresh rate
480i 60 Hz
480p 60 Hz
576i 50 Hz
576p 50 Hz
720p 50, 60 Hz
1080i 50, 60 Hz
1080p 24, 25, 30 Hz
1080p 50, 60 Hz
Sound
• Output power (RMS): 2 x 8 W
• Sound Enhancement: Digital Signal Processing,
Gra
phic Equalizer, Dynamic Bass Enhancement
• Sound System: Virtual Dolby Digital, BBE
Loudspeakers
• Built-in speakers: 4
• Loudspeaker types: Integrated woofers with
wOO
x, Dome tweeter
Convenience
• Child Protection: Child Lock+Parental Control
• Clock: Smart Clock
• Ease of Installation: Auto Programme Naming,
Autom
atic Channel Install (ACI), Automatic
Tuning System (ATS), Autostore, PLL Digital
Tuning, Plug & Play
• Ease of Use: Four favourite lists, Auto Volume
Leve
ller (AVL), Delta Volume per preset,
Graphical User Interface, On-Screen Display,
Programme List, Settings assistant Wizard, Side
Control
• Electronic Programme Guide: Now + Next EPG,
8-day
Electronic Programme Guide
• Remote Control: TV, DVD, HTS (Home Theatre
Sy
stem), STB (Set-Top Box)
• Remote control type: RC4422
• Screen Format Adjustments: unscaled (1080p dot
by
dot), 4:3, Auto Format, Movie expand 14:9,
Movie expand 16:9, Super Zoom, Widescreen
• Picture in Picture: Text dual screen
• Teletext: 1200-page Hypertext
• Teletext enhancements: Habit Watch, Programme
info
rmation Line
• Firmware upgradeable: Firmware auto upgrade
wizar
d, Firmware upgradeable via USB
• Multimedia: Digital media reader (browser), USB
autob
reak-in
Multimedia Applications
•Memory Card Types: Compact Flash type I,
Compact Flash type II, Memory Stick, Microdrive,
MultiMedia Card (MMC), Secure Digital Card (SD),
Smart Media Card
• Multimedia connections: USB, 7-in-1 Memory Card
Re
ader
• Playback Formats: MP3, Slideshow files (.alb), JPEG
St
ill pictures
Tuner/Reception/Transmission
• Aerial Input: 75 ohm coaxial (IEC75)
• TV system: DVB COFDM 2K/8K
• Video Playback: NTSC, SECAM, PAL
• DVB: DVB Terrestrial*
• Tuner bands: Hyperband, S-Channel, UHF, VHF
Connectivity
• Ext 1 Scart: Audio L/R, CVBS in/out, RGB
• Ext 2 Scart: Audio L/R, CVBS in/out, RGB
• Ext 3: YPbPr, Audio L/R in
• Ext 4: HDMI v1.3
• Ext 5: HDMI v1.3
• Ext 6: HDMI v1.3
• HDMI features: Cable equalization, Category 1 and
2 c
ables, Compressed audio, Multi-rate pref.
format support, PC format support, Resolutions
720p, 1080i, 1080p
• Front/Side connections: Audio L/R in, CVBS in,
Headpho
ne out, S-video in, USB, Multi-slot
memory card reader
• Other connections: Analogu
e audio Left/Right out,
S/PDIF out (coaxial), Common Interface
Power
• Ambient temperature: 5°C to 35°C
• Mains power: AC 220-240 V +/- 10%
• Power consumption: 232 W
• Standby power consumption: 0.8 W
Accessories
• Included Accessories: Tabletop swivel stand, RF
antenna cable
Dimensions
• Colour cabinet: Brilliant Pearl
•Set dimensions (W x H x D):
10
60 x 675 x 125 mm
• Set dimensions with stand (H x D): 740 x 256 mm
• Product weight: 28.7 kg
• Product weight (+stand): 32.4 kg
•Box dimensions (W x H x D):
11
60 x 881 x 310 mm
• Weight incl. Packaging: 39.7 kg
• VESA wall mount compatible: 600 x 400 mm
•
Issue date 2009-08-12
Version: 8.0.22
12 NC: 8670 000 24416
EAN: 87 12581 30061 6
© 2009 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
* DVB-T, supported in selected countries only
