Setting Up the Machine on a Network
34
3
*1
You can make the TCP/IP settings if SmartNetMonitor for Admin is communicating
with the machine using IPX/SPX.
*2
You can make the IPX/SPX settings if SmartNetMonitor for Admin is communicat-
ing with the machine using TCP/IP.
Settings You Can Change with
User Tools
Interface Settings/Network
❖
❖❖
❖ IP Address
Before using this machine in the
network environment, you must
configure the IP address and sub-
net mask.
• Auto-Obtain (DHCP)
• Specify
When you select [Specify], enter
the [IP Address]and [Sub-net
Mask] as “xxx.xxx.xxx.xxx”(“x”
indicates a number).
• IP Address: 011.022.033.044
• Sub-net Mask: 000.000.000.000
Note
❒ Default: Auto-Obtain (DHCP)
❒ If you use the interface for Eth-
ernet and IEEE 1394 (IP over
1394) at the same time, settings
must be made with care.
❒ If you install the IEEE 1394 in-
terface board (optional) and use
the IEEE 1394 interface, you
must set the address of the do-
main, different from the [IP Ad-
dress] of [IEEE 1394]. If you
intend to set the address for the
same domain, set a different
value for the [Sub-net Mask].
❒ When you select [Specify], be
sure not to set the same [IP Ad-
dress] as that of another ma-
chines on the network.
❒ The physical address (MAC ad-
dress) also appears.
File
Transfer
Max. Reception E-mail Size ❍ --
E-mail Storage in Server ❍ --
Default User Name/ Password (Send) ❍ --
Program/ Change/ Delete E-mail Message - - -
Program/ Change/ Delete Subject - - -
Scanner Recall Interval Time - - -
Number of Scanner Recalls - - -
E-mail Account - - -
Name on the control panel
Web
browser
Smart-
NetMon-
itor for
Admin
telnet
