Communicating with Devices on an EtherNet/IP Link 6-19
The following table shows example source and destination tags and elements
for different controller combinations.
When the DriveLogix controller initiates messages to PLC or SLC controllers,
you do not have to map compatibility files. You enter the data table address of
the target device just as you would a tag name.
SLC 5/05 controllers, SLC 5/04 controllers (OS402 and above), and
SLC 5/03 controllers (OS303 and above) support logical ASCII addressing
and support PLC/SLC mapping (see the examples above). For all other SLC
or MicroLogix1000 controllers, you must map a PLC-2 compatibility file (see
the PLC-2 examples above).
Type of MSG Instruction: Example Source and Destination:
PLC-5 writes to DriveLogix
SLC writes to DriveLogix
SLC 5/05
SLC 5/04 OS402 and above
SLC 5/03 OS303 and above
source element N7:10
destination tag “array_1”
The PLC-5, PLC-3, and SLC controllers support logical ASCII addressing so you do not
have to map a compatibility file for MSG instructions initiated by a PLC-5, PLC-3, or SLC
controller. Place the DriveLogix tag name in double quotes (“).
You could optionally map a compatibility file. For example, if you enter 10 for the
compatibility file, you enter N10:0 for the destination tag.
PLC-2 writes to DriveLogix source element 010
destination tag 200
The destination tag is the three-digit PLC-2 address you specified for PLC-2 mapping.
PLC-5 reads from DriveLogix
SLC reads from DriveLogix
SLC 5/05
SLC 5/04 OS402 and above
SLC 5/03 OS303 and above
source tag “array_1”
destination element N7:10
The PLC-5, PLC-3, and SLC controllers support logical ASCII addressing so you do not
have to map a compatibility file for MSG instructions initiated by a PLC-5, PLC-3, or SLC
controller. Place the DriveLogix tag name in double quotes (“).
You could optionally map a compatibility file. For example, if you enter 10 for the
compatibility file, you enter N10:0 for the source tag.
PLC-2 reads from DriveLogix source tag 200
destination element 010
The source tag is the three-digit PLC-2 address you specified for PLC-2 mapping.
