Specifications
90 Runco LS-1 Installation/Operation Manual
P
RELI
M
INARY
Performance
Microdisplay: Texas Instruments DLP® 1080p DMD
Native Resolution: Full HD, 1920 x 1080 (2,073,600 pixels)
Aspect Ratios: Native (Pixel-to-Pixel), 16:9, Letterbox, 4:3, 4:3 Narrow,
Letterbox (Anamorphic lens compatible)
Projection Lens: All glass, F/2.5~2.71, f = 39.1~50.1mm, 1.3x manual
zoom, made in Japan
Picture Size (16:9 Screen): Recommended Width: 63 in. (1.60 m) to 85 in. (2.16 m)
Maximum Width: 106 in. (2.69 m)
Throw Ratios: Refer to Table 3-3
Vertical Lens Shift Range
(Ceiling Mount):
Down = 25% to 60% of screen height below lens center
(50% to 120% of one half of the screen height)
Light Output: 35 Foot-Lamberts (fL) (CSMS); 780 ANSI Lumens
Home Theater Calibration: 541 ANSI Lumens (CSMS)
Sequential Contrast –
ConstantContrast On:
10,000:1 typical
385:1 (CSMS)
Cooling Performance: High-efficiency, adaptive voltage side-to-side cooling
with low system acoustic noise level and low light
pollution cabinet
Projection Modes: Front, Rear, Ceiling (front/rear)
Lamp: User-replaceable 180W HPM, 4000 hour lifetime
Video Processing: Runco advanced ViVix processing with 10 bit
independent dual channel image processing, true 1080i
deinterlacing, MPEG artifact reduction (block and
mosquito noise), latest motion adaptive processing, 3D
noise reduction, detail enhancement, rich color
processing and noise reduction, less than one frame
latency
Calibration: Full RGB gain/offset control (White Balance), Gamma,
Contrast, Color Temperature, Brightness
Table 7-1. LS-1 Specifications (continued)
