7.2
DHD Controller
Specifications
Table 7-2 lists the DHD Controller specifications.
Table 7-2. DHD Controller Specifications
Aspect Ratios: 4:3, Letterbox, 16:9, VirtualWide, Cinema, Virtual Cinema,
Native
Video Standards: • HDMI and DVI with HDCP for digital video
• Component and RGB HDTV (1080p, 1080i, 720p)
• Component and RGB EDTV (576p, 480p)
• Component and Composite SDTV (576i, 480i)
• RGB SCART with adaptor
• NTSC (M, 4.43)
• PAL (B, G, H, I, N, M)
•SECAM (M)
Inputs: (4) HDMI with CEC and Deep Color
(1) Component/SCART (3 x RCA)
(2) Component/RGBHV (5 x BNC)
(3) Composite
Outputs: (1) HDMI with Deep Color to V-50HD/V-63HD
(1) HDMI with Deep Color to second display or audio
processor
Control Options: • Discrete infrared (IR) remote
• RS-232 (female DB9) for serial commands
• Consumer Electronics Control (CEC) protocol support via
HDMI
•Ethernet
Ethernet Communication: RJ45 (female) for web server, e-mail, auto firmware upgrade
and Telnet
RS-232 Communication
Parameters:
19200 bps, no parity, 8 data bits, 1 stop bit, no flow control
Accessory Applications: Runco Firmware Upgrader, Runco BRiC (backup, restore,
clone), CalMAN by SpectraCal for automatic calibration
Power Requirements: 100-240V~, 47-63Hz, 0.45 Amps
Operating Environment: 41°F to 104°F (5°C to 40°C), 0% to 90% humidity
(non-condensing); up to 10,000 feet (3,048 meters) altitude
Dimensions: Width = 17.50 inches (444.5 mm)
Depth = 11.19 inches (284.1 mm)
Height = 3.75 inches (95.3 mm)
Weight: 15.4 lbs. (7.00 kg)
Regulatory Approvals: cTUVus, FCC class B, CE, RoHS, China RoHS, WEEE,
C-Tick, CCC, local conformances as required
Limited Warranty: Two (2) years parts and labor from the date of shipment from
Runco.
Specifications are subject to change without notice.
