8-GB
Parts identification
See pages in ( ) for more details.
To insert the floppy disk
Insert the floppy disk until it clicks.
Before inserting, check that the
write protect tab set to the
recording position.
To remove the floppy disk
While pressing PUSH, slide DISK EJECT in the direction of the arrow.
DISK EJECT lever
PUSH button
Shutter button (16, 17)
Self-timer lamp
The lamp keeps on blinking
until recording starts after the
shutter button is depressed.
Flash emitter (10)
Lens
FOCUS AUTO/
MANU switch (34)
Tripod receptacle
Make sure that the length of
the tripod screw is less than
7/32 inch (6.5 mm).
Focus ring (34)
Slot for AC
power adaptor code
Photocell window
for flash
Do not block when
recording.
Lens cap
Microphone
Do not touch when
recording.
