51

5-3 Details of Functions

Chapter 5 Using the Utility Software

TIME CODE

Item name Settings

TC MODE Select the time code

recording mode.

INT-REGEN

: Record

the output of the

internal time code

generator,

initialized to time

code following

continuously upon

the time code of the

last frame of the

last clip on the disc.

EXT-REGEN: Record

the output of the

internal time code

generator,

synchronized to an

external time code

generator.

DF MODE In 525-line mode, select

the run mode of the

internal time code

generator.

ON (DF)

: Drop-frame

mode

OFF (NDF): Non-drop

frame mode

VITC Specify whether or not

to record the VITC

generated by the

internal time code

generator.

OFF: Do not record

internally

generated VITC.

ON

: Record internally

generated VITC.

AUDIO CONTROL

Item name Settings

DV AUDIO

OUTPUT

SELECT

Select the audio

signals to assign to

i.LINK(AV/C) audio

output channels.

Sub-item

1 CH1/CH2 tr1/2: Tracks 1 and 2

assigned to audio

output channels 1

and 2.

tr3/4: Tracks 3 and 4

assigned to audio

output channels 1

and 2.

tr5/6: Tracks 5 and 6

assigned to audio

output channels 1

and 2.

tr7/8: Tracks 7 and 8

assigned to audio

output channels 1

and 2.

2 CH3/CH4 tr1/2: Tracks 1 and 2

assigned to audio

output channels 3

and 4.

tr3/4

: Tracks 3 and 4

assigned to audio

output channels 3

and 4.

tr5/6: Tracks 5 and 6

assigned to audio

output channels 3

and 4.

tr7/8: Tracks 7 and 8

assigned to audio

output channels 3

and 4.

DV OUT

AUDIO MODE

Select the audio mode

for S400 (i.LINK)

connector (output).

4ch: 12 bit/32 kHz/4ch

2ch

: 16 bit/48 kHz/2ch

AUDIO CONTROL

Item name Settings
