111FT-857 Operating Manual
MENU MODE No-083
[
TONE FREQ
]
Function: Setting of the CTCSS Tone Fre-
quency.
Available Values: 50 Standard CTCSS tones
Default: 88.5 Hz
MENU MODE No-084
[
TOT TIME
]
Function: Selects the Time-Out Timer time.
Available Values: OFF/1 ~ 20 (min)
Default: OFF
MENU MODE No•085
[
TUNER/ATAS
]
Function: Selects the device (FC-30 or ATAS-100/-120) to be controlled via the front
panel’s
[
A
](
TUNE
)
key.
Available Values: OFF/ATAS(HF)/ATAS(HF&50)/ATAS(ALL)/TUNER
Default: OFF
OFF: The
[
A
](
TUNE
)
key is disabled.
ATAS (HF): The
[
A
](
TUNE
)
key will activate the optional ATAS-100/-120 on the HF
amateur bands.
ATAS (HF&50):The
[
A
](
TUNE
)
key will activate the optional ATAS-100/-120 on the HF
amateur bands and 50 MHz amateur band.
ATAS (ALL): The
[
A
](
TUNE
)
key will activate the optional ATAS-100/-120 on the HF,
VHF (6/2 m), and 430 MHz bands.
TUNER: The
[
A
](
TUNE
)
key will activate the optional FC-30.
MENU MODE No•086
[
TX IF FILTER
]
Function: Selects the Transmit IF filter.
Available Values: CFIL/FIL1/FIL2
Default: CFIL
MENU MODE No•087
[
VOX DELAY
]
Function: Sets the “hang time” for the VOX circuitry.
Available Values: 100 ~ 3000 (ms)
Default: 500 (ms)
MENU MODE No-088
[
VOX GAIN
]
Function: Sets the gain of the VOX circuitry’s input audio detector.
Available Values: 1 ~ 100
Default: 50
MENU OPERATION
CTCSS TONE FREQUENCY
(
Hz
)
67.0 69.3 71.9 74.4 77.0 79.7
82.5 85.4 88.5 91.5 94.8 97.4
100.0 103.5 107.2 110.9 114.8 118.8
123.0 127.3 131.8 136.5 141.3 146.2
151.4 156.7 159.8 162.2 165.5 167.9
171.3 173.8 177.3 179.9 183.5 186.2
189.9 192.8 196.6 199.5 203.5 206.5
210.7 218.1 225.7 229.1 233.6 241.8
250.3 254.1 – – – –
