Parts List
Main Unit
DESCRIPTION VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.REF. LOT. SIDE LAY ADR
*** MAIN-UNIT ***
PCB with Components (W/ VR-UNIT) CP6946001 VERSION D
PCB with Components (W/ VR-UNIT) CP6946003 VERSION A
PCB with Components (W/ VR-UNIT) CP6946005 CS VERSION
PCB with Components (W/ VR-UNIT) CP6946007 VERSION A, CE
PCB with Components (W/ VR-UNIT) CP6946008 VERSION CS, CE
PCB with Components (W/ VR-UNIT) CP69460011 VERSION F
Printed Circuit Board FR006560C 1-
Printed Circuit Board FR006560D 5-
C 1001 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1- B c1
C 1002 CHIP CAP. 22pF 50V CH GRM36CH220J50PT K22178220 1- B c2
C 1003 CHIP CAP. 10pF 50V CH GRM36CH100D50PT K22178212 1- B b2
C 1004 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- A C7
C 1005 CHIP CAP. 8pF 50V CH GRM36CH080D50PT K22178210 1-6 B c2
C 1005 CHIP CAP. 9pF 50V CH GRM36CH090D50PT K22178211 CS VERSION 7- B c2
C 1005 CHIP CAP. 12pF 50V CH GRM36CH120J50PT K22178214 VERSION A 7- B c2
C 1005 CHIP CAP. 8pF 50V CH GRM36CH080D50PT K22178210 VERSION D 7- B c2
C 1005 CHIP CAP. 7pF 50V CH GRM36CH070D50PT K22178209 VERSION F 8- B c2
C 1006 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a4
C 1007 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B a4
C 1008 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A C3
C 1009 CHIP CAP. 2pF 50V CK GRM36CK020C50PT K22178204 1- B c2
C 1009 CHIP CAP. 2pF 50V CK GRM36CK020B50PT K22178289 6 B c2
C 1009 CHIP CAP. 2pF 50V CK GRM36CK020B50PT K22178289 CS VERSION 7- B c2
C 1009 CHIP CAP. 3pF 50V CJ GRM36CJ030B50PT K22178290 VERSION A 7- B c2
C 1009 CHIP CAP. 2pF 50V CK GRM36CK020B50PT K22178289 VERSION D 7- B c2
C 1009 CHIP CAP. 2pF 50V CK GRM36CK020B50PT K22178289 VERSION F 8- B c2
C 1010 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A C4
C 1011 CHIP CAP. 6pF 50V CH GRM36CH060D50PT K22178208 1-6 B c2
C 1011 CHIP CAP. 6pF 50V CH GRM36CH060D50PT K22178208 CS VERSION 7- B c2
C 1011 CHIP CAP. 8pF 50V CH GRM36CH080D50PT K22178210 VERSION A 7- B c2
C 1011 CHIP CAP. 7pF 50V CH GRM36CH070D50PT K22178209 VERSION A 10- B c2
C 1011 CHIP CAP. 6pF 50V CH GRM36CH060D50PT K22178208 VERSION D 7- B c2
C 1011 CHIP CAP. 5pF 50V CH GRM36CH050C50PT K22178207 VERSION F 8- B c2
C 1013 CHIP CAP. 2pF 50V CK GRM36CK020C50PT K22178204 1- B c2
C 1013 CHIP CAP. 2pF 50V CK GRM36CK020B50PT K22178289 6 B c2
C 1013 CHIP CAP. 2pF 50V CK GRM36CK020B50PT K22178289 CS VERSION 7- B c2
C 1013 CHIP CAP. 3pF 50V CJ GRM36CJ030B50PT K22178290 VERSION A 7- B c2
C 1013 CHIP CAP. 2pF 50V CK GRM36CK020B50PT K22178289 VERSION D 7- B c2
C 1013 CHIP CAP. 2pF 50V CK GRM36CK020B50PT K22178289 VERSION F 8- B c2
C 1015 CHIP CAP. 56pF 50V CH GRM36CH560J50PT K22178230 1- B b2
C 1016 CHIP CAP. 0.0027uF 50V B GRM36B272K50PT K22178814 1- B a4
C 1017 CHIP TA.CAP. 4.7uF 6.3V TMCMA0J475MTR K78080026 1- B a4
C 1018 CHIP CAP. 150pF 50V CH GRM36CH151J50PT K22178240 1- B b2
C 1019 CHIP CAP. 7pF 50V CH GRM36CH070D50PT K22178209 1-6 B c2
C 1019 CHIP CAP. 7pF 50V CH GRM36CH070D50PT K22178209 CS VERSION 7- B c2
C 1019 CHIP CAP. 10pF 50V CH GRM36CH100D50PT K22178212 VERSION A 7- B c2
C 1019 CHIP CAP. 7pF 50V CH GRM36CH070D50PT K22178209 VERSION D 7- B c2
C 1019 CHIP CAP. 6pF 50V CH GRM36CH060D50PT K22178208 VERSION F 8- B c2
C 1020 CHIP CAP. 1pF 50V CK GRM36CK010C50PT K22178202 1-7 B c2
C 1020 CHIP CAP. 1pF 50V CK GRM36CK010C50PT K22178202 CS VERSION 8- B c2
C 1020 CHIP CAP. 1pF 50V CK GRM36CK010C50PT K22178202 VERSION A 8- B c2
C 1020 CHIP CAP. 1pF 50V CK GRM36CK010C50PT K22178202 VERSION D 8- B c2
C 1020 CHIP CAP. 0.5pF 50V CK GRM36CK0R5B50PT K22178285 VERSION F 8- B c2
C 1021 CHIP TA.CAP. 1uF 16V TMCSA1C105MTR K78120023 1- B a7
C 1023 CHIP CAP. 0.1uF 10V B GRM36B104K10PT K22108802 1- B a7
C 1024 CHIP CAP. 0.001uF 50V B GRM36B102K50PT K22178809 1- B b2
C 1025 CHIP CAP. 1pF 50V CK GRM36CK010C50PT K22178202 1-7 B c2
C 1025 CHIP CAP. 1pF 50V CK GRM36CK010C50PT K22178202 CS VERSION 8- B c2
C 1025 CHIP CAP. 1pF 50V CK GRM36CK010C50PT K22178202 VERSION A 8- B c2
