5-35
FRONT FORK
5. Install:
• Protector "1"
• Bolt (protector) "2"
6. Adjust:
• Rebound damping force
Turn in the damping adjuster "1" finger-tight
and then turn out to the originally set position.
7. Adjust:
• Compression damping force
Turn in the damping adjuster "1" finger-tight
and then turn out to the originally set position.
Bolt (protector):
5 Nm (0.5 m•kg, 3.6 ft•lb)
