Elite Screens 022111AS Home Theater Screen User Manual


  Open as PDF
of 7

5
Rev.022111‐AS
www.elitescreens.com
 info@elitescreens.com
Thelistedmeasurementsareforgeneralreferenceonly.PleasecontactEliteScreenstoverifyproductdesignanddimensions
beforeattemptingtointegrateitsproductswithanystructuralor furnituremodification.Althoughamanufacturermayoffer
productadvice,itmaybetakenordisregardedattheintegrator’sdiscretion.EliteScreenswillnot
beheldresponsibleorbe
otherwiseliableforfaultyinstallations

Unit:mm    
Model
Diagonal
&
RatioSize
View
Height
(A)
View
Width(B)
Thickness
(C)
iRP74V 74"(4:3) 1125 1500 0.10
iRP99V 99"(4:3) 1500 2000 0.10
iRP68H 68"(16:9) 844 1500 0.10
iRP103X‐100H 103"/100"(16:10/9) 1500 2210 0.10
iRP121H 121"(16:9) 1500 2666 0.10
iRP70X 70"(16:10) 938 1500 0.10
iRP112X 112"(16:10) 1500 2400 0.10
iRP151C 151"(2.35:1) 1500 3525 0.10
iRP10m N/A 1500 10000 0.10
Unit:inch    
Model
Diagonal
&
RatioSize
View
Height(A)
View
Width(B)
Thickness
(C)
iRP74V 74"(4:3) 44.3 59.1 0.0039
iRP99V 99"(4:3) 59.1 78.7 0.0039
iRP68H 68"(16:9) 33.2 59.1 0.0039
iRP103X‐100H 103"/100"(16:10/9) 51.9 87.0 0.0039
iRP121H 121"(16:9) 59.1 104.9 0.0039
iRP70X 70"(16:10) 36.9 59.1 0.0039
iRP112X 112"(16:10) 59.1 94.5 0.0039
iRP151C 151"(2.35:1) 59.1 138.8 0.0039
iRP10m N/A 59.1 393.7 0.0039
Insta-RP Dimensions Table
