Rev.102111-AS
www.elitescreens.com info@elitescreens.com
Please make sure all items listed below are included before proceeding with the installation.
Please consult a professional installer. Elite Screens is not liable for any faulty installations.
1. Insert each Bolt (B) through the right & left slide channel located on the top of the screen’s case.
2. Slide the Extruded Hanging Bracket (D) through the rail located below the slide channel until it
meets with the top of the Bolt (B) and slightly secure the lug-nuts located on the top & bottom
of the bolt to attach the bracket.
Hardware Parts List
QTY
A
.
Screw & Dry Wall Anchor
2EA.
B
.
Bolt
2
C
.
Masonry Screw & Anchor
2EA.
D
.
Extruded Hanging Bracket
2
or 3
Hardware Parts List for CineTension 2 Series
A
B
C
D
120” & above x 3
brackets
Installation Instructions
