TROUBLESHOOTING GUIDE
Sometimes a performance problem can be easily solved by checking seemingly apparent but often overlooked possibilities. Before arranging for service, check these items. It could save your time and
money.
GENERAL SPECIFICATIONS
Television system: NTSC-M
TV Standard
Channel coverage
VHF: 2 ~ 13
UHF: 14 ~ 69
CATV: 2 ~ 13, A ~ W,
W+1 ~ W+84,
A-5 ~ A-1, 5A
Tuning System 181 channel
frequency synthesized
tuning system
Channel access: Direct access keyboard,
programmable
scan and up/down
Antenna terminals: VHF/UHF/CATV
75 ohm unbalanced
(F-type)
Video input: RCA connector x 2
Audio input: RCA connector x 2
Video output: RCA connector x 1
Audio output: RCA connector x 1
Remote terminal: RCA connector x 1
Speaker terminal: RCA connector x 1
DC input: DC power jack x 1
ELECTRICAL SPECIFICATIONS
Sound output: 1W, 8 ohm
OTHER SPECIFICATIONS
Remote control: Digital encoded
infrared light system
Operating
temperature: 5°C to 40°C
(41°F~104°F)
Power requirements: DC 13.2V
Power consumption
(Maximum): 47W
Picture tube: 9"
Dimensions: H : 8-9/16"(218mm)
W: 9-13/16"(250mm)
D: 11-1/2"(292mm)
Weight: 11 lbs. (5 kg)
Accessories: Owner’s manual
Remote Control unit
with 2"AA"batteries
•Designs and specifications are subject to
change without notice.
•If there is a discrepancy between languages,
the default language will be English.
QUICK SERVICE CHECK LIST
PROBLEM
POSSIBLE REMEDY
Try a new channel, if OK, then possible
station trouble.
Is TV plugged in?
Is TV’s POWER button on?
Is antenna connected to terminal on the
back of the set?
If outside antenna is being used, check
for broken wire.
Check for local interference.
Turn off with POWER button and then
turn it on after about a minute.
Adjust COLOR control.
Adjust CONTRAST & BRIGHT
control.
Check batteries in Remote Control.
Remote Control Doesn’t Work
Bars On Screen
Picture Distorted
Picture Rolls Vertically
No Color
Poor Reception on Some Channels
Weak Picture
Lines or Streaks in Picture
Ghosts in picture
Picture Blurred
Sound OK, Picture Poor
Picture OK, Sound Poor
No Picture or Sound
MAINTENANCE
CABINET CLEANING
● Wipe the front panel and other exterior surfaces of the TV with a soft cloth immersed in luke-
warm water and wrung dry.
● Never use a solvent or alcohol. Do not spray insecticide liquid near the TV. Such chemicals
may cause damage and discoloration to the exposed surfaces.
PICTURE TUBE CLEANING
Wipe the picture tube of the TV with a soft cloth. Before cleaning the picture tube, disconnect the
power cord.
POWER CORD
This TV has DC 13.2V jack on the back of the TV.
This jack must be connected to DC source in a car.
Notes:
● The DC plug cable is not supplied in the TV. If you need the DC plug cable (Part No. 60035),
please consult with TEXAS SADDLEBAGS, INC. (Telephone 1-800-521-2997).
● Refer to “TV TO VEHICLE CONNECTION”
SUPPLIED ACCESSORIES
SPECIFICATIONS: RFT909B
As an ENERGY STAR
Partner, our company has
determined that this product meets
the E
NERGY STAR guidelines for
energy efficiency. E
NERGY STAR is
a U.S. registered mark.
®
®
®
Remote control unit
(N0106UD)
Batteries ("AA" x 2)
L0941.QX33 02.8.28 6:17 PM Page 4
