Additional preparation
39
AV-32/28R47SK / LCT1569-001A-U / ENGLISH
Audio amplifier and front speakers
You can use external front speakers to listen
to the TV sound instead of the TV speakers.
Also note that when you want to use the
DOLBY PRO LOGIC II MUSIC or DOLBY
PRO LOGIC II MOVIE, you can set it to
issue sound from both of the TV speakers
and external front speakers so that you can
listen to spoken dialogues more clearly and
easily. For details, see “Surround function
(Dolby Pro Logic II)” on page 16.
You cannot cut the sound from the front
speaker even if you connect headphones
to the TV.
External surround speakers
You can connect external surround speakers
to the TV so that you can use the “DOLBY
PRO LOGIC II MUSIC:” or “DOLBY PRO
LOGIC II MOVIE:” on page 17. Before
using the DOLBY PRO LOGIC II MUSIC or
DOLBY PRO LOGIC II MOVIE, however,
follow “Surround settings (Dolby Pro Logic
II)” on page 17.
Positioning the speakers
R
AUDIO OUT
SURROUND
REAR
L
3
2
1
123
1 Amplifier
2 Front speakers (magnetic-shielded type)
3 Surround speakers (impedance 8 ohm type)
(Terminals on rear)
L
R
Approx.
45 degrees
