JVC DR-MV99BU DVD Recorder User Manual



54
General
Power requirements AC 120V, 60 Hz
Power consumption 32W
Dimensions (approx.) 430 X 78.5 X 260 mm (16.9 x 3.1 x 10.2 inches) (w x h x d)
Net Weight (approx.) 5.8 kg (12.79 lbs)
Operating temperature 5˚C to 35˚C (41˚F to 95˚F)
Operating humidity 5 % to 90 %
Signal system NTSC, DTV standard ATSC or Clear QAM over cable
Recording
Recording format DVD VideoRecording, DVD-VIDEO
Recordable discs DVD+/-Recordable; DVD+/-Rewritable
Recordable time DVD; Approx. 1 hour (XP mode), 2 hours (SP mode),
4 hours (LP mode), 6 hours (EP mode)
VCR; SP: 2 HOURS (T-120), SLP: 6 HOURS (T-120)/8 HOURS (T-160)
Video recording format
Sampling frequency 27MHz
Compression format MPEG 2 (VBR support)
Audio recording format
Sampling frequency 48kHz
Compression format Dolby Digital
VCR Specifications
Head system Four head helical scan azimuth system
Timer 12-hour display type with AM, PM
Tape speed SP: 33.35 mm/sec, LP: 16.67 mm/sec, SLP: 11.12 mm/sec
Tape width 12.7 mm
Rewind time About 180 seconds (T-120)
Antenna 75 ohms (VHF/UHF)
VHF output signal Channel 3 or 4 (Switchable)
Channel coverage Analog (VHF: 2-13, UHF: 14-69, CATV: 1-135)
Digital (Terrestrial: 2-69, Cable: 1-135)
Frequency range 20Hz to 20kHz
Signal-to-noise ratio 43dB
Dynamic range 88 dB
Channel separation 60 dB
