JVC HR-VP655U VCR User Manual



20 EN
INITIAL SETTINGS (cont.)
Set DBS Receiver Output
Channel & DBS Receiver
Brand
Turn on the TV and select the VCR channel 3 or 4 (or AV
mode).
TURN ON DBS RECEIVER
1
Select a channel other than channel 55, 100 or 205 on
your DBS receiver.
TURN ON THE VCR
2
Press POWER.
Set the VCR to the channel (3 or 4 or F-1 or L-1) on
which the signals from the DBS receiver are received.
ACCESS MAIN MENU
SCREEN
3
Press MENU.
ACCESS INITIAL SET
SCREEN
4
Press CH5
or SHUTTLE PLUS%
to move the
highlight bar (arrow) to “INITIAL SET”, then press OK or
SHUTTLE PLUS .
ACCESS DBS RECEIVER SET
SCREEN
5
Press CH5
or SHUTTLE
PLUS%
to move the
highlight bar (arrow) to
“DBS RECEIVER SET”, then
press OK or SHUTTLE
PLUS .
SELECT DBS RECEIVER
OUTPUT CHANNEL
6
Your selection depends on
how your DBS receiver is
connected to your VCR.
If your DBS receiver is
connected to your VCR
using an RF connection . . .
. . . press CH 5
or
SHUTTLE PLUS %
until
the channel number
representing the DBS receiver's output (CH3 – CH4)
appears on the screen.
If your DBS receiver is connected to your VCR's
FRONT AUDIO/VIDEO IN connectors . . .
. . .
press
CH 5
or SHUTTLE PLUS %
until "ON F-1
(FRONT)" appears on the screen
.
If your DBS receiver is connected to your VCR’s REAR
AUDIO/VIDEO IN connectors . . .
. . . press CH 5
or SHUTTLE PLUS %
until "ON L-1
(REAR)" appears on the screen.
%
%
POWER
OK
MENU
123
456
7
89
0
2
4
1
3
POWER
MENU
OK
SHUTTLE PLUS
CH
INITIAL SET
CLOCK SET
LANGUAGE ENGLISH
GUIDE CHANNEL SET
CABLE BOX SET
=DBS RECEIVER SET
SELECT WITH (5,) AND (OK)
PRESS (MENU) TO END
DBS RECEIVER SET
OFF
PRESS (5,), THEN (OK)
PRESS (MENU) TO END
