- 4 -
SPECIFICATIONS
Note : Specification and others are subject to change without notice for improvement.
¡ Video input system:
PAL-B/G, D/K, I/I
SECAM-B/G, D/K/L/L’
NTSC M
NTSC 4.43(AV)
¡ Intermediate Frequency (Unit : MHz)
VISION IF : 38.9MHz,33.9MHz(SECAM-L’)
COLOR IF : 34.47MHz(4.43)
35.32MHz(3.58) : NTSC-M
VIF-4.25000MHz
VIF-4.40625MHz
SOUND IF : 33.4MHz (B/G)
32.9MHz (I/I)
32.4MHz (D/K,L)
34.4MHz (M)
40.4MHz (L’)
¡ Power requirement : 110~240V, 50/60Hz
¡ Power consumption : 100W
¡ CPT : True Flat CPT(Flatron)
¡ Tuning system :
FVS
100 Programme memory
200 Programme memory(For CHINA)
¡
Antenna input impedance : VHF/UHF 75 ohm, unbalanced
¡ OSD (On Screen Display) : MENU Type
¡ Voice coil impedance : 8 ohm
¡ Sound output : 12W+12W
Dual/Stereo : A2/NICAM(Option)
¡ External connection :
Head Phone Jack
S-VIDEO in
A/V in :1 pair
Scart 1(Full)
A/V in/out
Scart 2(Half)+Audio out
A/V in/out
¡ External In/Output
Audio-In:0.5Vrms¡ 3db,over 10Kohm
Audio-Out:0.5Vrms¡ 3db,below 1Kohm
Video-In/Out:1Vp-p¡ 3db,75ohm
R,G,B In:0.7Vp-p¡ 3db
¡ Feature : Auto programme/Manual programme
SVM (Scanning Velocity Modulation)
Digital Eye
Digital Comb Filter
Auto Sleep
Dynamic Focus
Programme Editing
PSM (Picture Status Memory)
CTI
Double Window Teletext (TOP/FLOF)
Turbo Search, Picture & Sound
ACMS
ARC (Zoom 1/ZOOM 2, 16:9¡Œ4:3)
1 TUNER PIP(Double Window PIP)
Child Lock :
¡ Tuning range
Band
VHF-Low
VHF-High
Hyper
UHF
S1'-S3', S1
S2-S10,
S11-S20
S21-S41
For TV
For CATV
B/G
Ch2-4
Ch5-12
D/K
Ch1-5
Ch6-12
I/I
Ch4-13
NTSC
Ch2-13
Ch21-69 Ch14-69
In the Lock On state the TV can only be
operated by the Remote Controller.
If any button on the front panel is pressed,
"Child Lock" is displayed on the screen but
the button's function is not performed.
To cancel of this mode, select lock off with
menu button on remote controller only.
(
): SECAM
Front or
Side
Back
