Daily handling
Remote control RC3
Remote control for operating different Loewe
units.
Operating the TV:
Set the rotary switch to ”TV”.
Ex-factory settings are: Loewe video recorder,
Loewe DVD recorder and for STB (Set Top Box)
the d-box common in Germany.
The remote control must be switched for
operating a Loewe DVD player.
TV equipment
Functions marked by ✳ are not available in all
types of TV sets but can usually be retrofitted.
Ask your dealer if you are interested.
Menu contents may differ from the ones shown
depending on your TV equipment.
Operation of the ”Digital Recorder”, if
available, are described in a separate operating
manual.
You can show your TV
equipment by pressing the
INFO button on the remote
control.
Select the ”Equipment” line in
the ”Main information” menu.
Press the OK button.
Hide the menu again with the
END button.
Use the drive buttons in TV- and STB
position for VCR, DVD or Digital Recorder
You can switch over the six drive buttons both
for TV and STB for operating a VCR or DVD
player/recorder. Operation of the built-in Digital
Recorder Plus is specified ex-factory.
First turn the switch to the main
function TV or STB.
Press the END and
*
EPG but-
tons at the same time (5 secs).
The display at the top left of the
remote control flashes twice.
Enter the numbers 988 one after
the other. The display again
flashes twice.
Now turn the switch to the
required function for the drive
buttons. DVD, VCR or TV if the
Digital Recorder is to be used.
Press the # PIP button to com-
plete the setting. The display
flashes twice.
The setting is saved.
Switching on/off
Your TV set is equipped with an economy
standby power supply unit. On standby the
power consumption drops to low power. If you
want to save even more electricity, switch the
set off at the On/Off switch (Signal Box).
But remember that EPG data will then be lost
and timed recordings will not be made.
When the TV is switched on,
you can switch it to standby
with the blue on/off button.
The red standby indicator on
the set
lights up. If the green indicator
is also alight a timer recording
on the VCR is in progress, EPG
data input is taking place or
radio mode without on-screen
display is active.
From standby it is best to
switch back on with the blue
On/Off button or with a
numeric key (station 0-9). The
green (blue) operating LED
then lights up.
When you switch on the TV
with OK, you see the station
table and can choose a station.
None of the indicators lights up when you
switch off the TV set with the On/Off button on
the set.
Switch on the TV set with the On/Off button
on the set when it is switched off.
TV
DVD STB
VCR
OK
OK
TV
DVD STB
VCR
EPG
TV
DVD STB
VCR
wxyz
tuv
tuv
PIP
OK
31936_021_Spheros42HDR+_GB 18.10.2004, 10:17 Uhr10
