SPECIFICATIONS
Reference
ENGLISH FRANÇAIS
DEUTSCH
NEDERLANDS
ESPAÑOL
ITALIANO
PORTUGUÊS
SVENSKA
GENERAL
Power requirements AC 110-240V, 50/60 Hz
Power consumption 14W
Dimensions (approx.) 435 X 55 X 241 mm (w x h x d)
Weight (approx.) 2.4 kg
Operating temperature 5˚C to 35˚C (41˚F to 95˚F)
Operating humidity 5 % to 90 %
SYSTEM
Laser Semiconductor laser, wavelength 650 nm
Signal system NTSC
Frequency response DVD (PCM 96 kHz): 8 Hz to 44 kHz
DVD (PCM 48 kHz): 8 Hz to 22 kHz
CD: 8 Hz to 20 kHz
Signal-to-noise ratio More than 100dB (ANALOG OUT connectors only)
Harmonic distortion Less than 0.008%
Dynamic range More than 100 dB (DVD)
More than 95 dB (CD)
OUTPUTS
VIDEO OUT 1 Vp-p 75 ohms, sync negative, RCA jack x 1
S-VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, Mini DIN 4-pin x 1
(C) 0.3 V (p-p) 75 ohms
COMPONENT VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, RCA jack x 1
(Pb)/(Pr) 0.7 V (p-p), 75 ohms, RCA jack x 2
Audio output (digital audio) 0.5 V (p-p), 75 ohms, RCA jack x 1
Audio output (optical audio) 5 V (p-p), 75 ohms, Optical connector x 1
INPUTS
+ 12V Trigger input center pin +12V at 50 mA, subminiature banana jack x 1
ACCESSORIES
Video cable 1
Audio cable 1
Remote control 1
Batteries 2
Design and specifications are subject to change without notice.
Manufactured under license from Dolby Laboratories. Dolby, MLP Lossless and the double-D symbol are trademarks of Dolby Laboratories.
Confidential unpublished works. Copyright 1992-1997 Dolby Laboratories. All rights reserved.
“DTS’ and “DTS Digital Out” are trademarks of Digital Theater Systems, Inc.
