Settings Using the On Screen
Display
Preparations
–Confirm that the TV is on and the VCR
viewing channel is selected.
–Turn on the VCR.
–Press [VCR/TV] to select the VCR mode.
On Screen Display
1 Press [MENU].
2 Select [OPTION] by
pressing 3 or 4 and
then press [OK].
3 Select [OSD] by
pressing 3 or 4.
4 Select [ON] or [OFF] by
pressing 2 or 1.
ON: The on screen display will appear on
the TV screen for 5 seconds.
–The on screen display will always appear
on the TV screen during rewind and fast
forward.
OFF: The on screen display will not appear.
5 Press [MENU] twice to make the on screen
display disappear.
To Use the On Screen Display
Press [OSD/DISPLAY].
1 L and R Indicators
2 Indicator for STEREO and SAP
Reception
When receiving a TV program,
automatically indicates when a TV
program is broadcast with the stereo and/
or AUDIO II (SAP) sound system.
At the every push of [AUDIO], the audio
output mode changes as follows. During
playback:
Stereo>L>R>Normal audio track
>Stereo
While the broadcast signals are being
received:
Stereo>L>R>Stereo
The Left (L) and Right (R) indicators show
which sound mode is selected as follows
on the On Screen Display.
Stereo: Both the L and R indicators
appear.
L: The L indicator appears.
R: The R indicator appears.
Normal: Neither the L nor R indicator
appears.
3 Program position
CH 1
STEREO
L R
345
6
0:00.22
SP
21
8
7
STANDARD
LANGUAGE
CLOCK SET
OCHANNEL SET
SELECT
END
: , OK
:MENU
OSD MENU
¡OPTION
OSD ≥ON OFF
TAPE SELECT
≥T120 T160 T180
BLUE BACK ≥ON OFF
JET NAVIGATOR ≥ON ≥OFF
DELETE NAVIDATA ≥NO YES
JET SEARCH x27 ≥x35
END :MENU
SELECT : s/r:
OSD ≥ON OFF
TAPE SELECT
≥T120 T160 T180
BLUE BACK ≥ON OFF
JET NAVIGATOR ≥ON ≥OFF
DELETE NAVIDATA ≥NO YES
JET SEARCH x27 ≥x35
END :MENU
SELECT : s/r:
OPTION 1/2
OPTION 1/2
