Quick Start Guide
OPTION
MULTI PIP
POWER
SD CARD
EXIT
ASPECT
RETURN
INPUT
SURROUND
REC
POWER
RECALL MUTE
CH VOL
F.P.
GRYB
S
VIDEO
VIDEO
AUDIO
AV IN
3
AV4 IN
L
R
Changes the
input mode
Identifying Controls
•
Identifying Controls
•
Accessories / Options
Cursor buttons to make selections and
adjustments
Standby On / Off switch
(Switches TV On or Off standby)
Sound mute On / Off
Multi window (p. 13)
Selects programmes in sequence
When in Standby mode, switches TV On.
Teletext (p. 16)
OK button to confi rm selections and choices
Press after selecting programme positions to
quickly change programme.
VCR / DVD operations (p. 15)
Volume
Programme Information
(p. 13)
Teletext Index (p. 17)
Coloured buttons used for the
selection, navigation and operation of
various functions
EXIT (Returns to TV screen)
Surround (p. 20)
Programme / channel change buttons (0-9)
and Teletext page buttons.
(p. 12 and p. 16)
When in Standby mode, switches TV On.
Access VIERA Link Menu (p. 33)
Changes aspect ratio (p. 13)
Option menu
Sets the preferred settings of viewing
and sound options easily (p. 12)
Main Menu (p. 18)
Press to access VIERA Link, Picture, Sound
and Setup menus
Viewing a favourite teletext channel (p. 17)
Stereo / Bilingual Sound Selection (p. 40)
Changes the input mode
TV -
changes TV mode
(p. 14)
AV - changes AV input mode (p. 14)
Viewing SD Card (p. 30)
Returns to the previous menu
Still picture (p. 12)
Teletext Hold (p. 17)
C.A.T.S. (Contrast Automatic Tracking
System) sensor
•
Senses brightness to adjust picture quality in
“Eco” mode in Picture Menu (p. 20)
Mains power On / Off switch
•
Switch On to turn on the TV or
turn the TV to standby mode by
the remote control
Increases or decreases the
programme position by one. When a
function is already displayed, press
to increase or decrease the selected
function. When in Standby mode,
switches TV On.
Function select
•
Volume / Contrast / Brightness / Colour / Sharpness /
Tint (NTSC mode) / Bass / Treble / Balance / Auto Tuning (p. 25)
SD Card slot (p. 31)
Headphones
jack (p. 36)
Power LED
•
Standby: red
On: green
•
When using the remote control, indicates the TV has received a command.
Swing door
to open
AV4 terminals
(p. 36)
Remote control
signal receiver
