D:\SONY TV\SY130295_Clover 16\4531417111_US\US03STU.fm
KDL-55W950B
4-531-417-11(1)
19
US
US
The length of the M4 machine screw
differs depending on the rope or chain
diameter. Please see below illustration.
3 Anchor the TV to the wall by using bolts,
wall anchor and chain (or rope).
~
• Your TV is shipped with screws attached
to the rear of the TV depending on the TV
model. (They are fastened in the screw
holes for wall mounting.) Be sure to
remove the upper two screws prior to
anchoring the TV to a wall.
• Securing the TV to the stand without
securing the TV and the stand to the wall
provides minimum protection against the
TV toppling over. For further protection,
be sure to follow the three measures
recommended.
Screw M4
Rope or chain
TV’s rear cover
6-8 mm
Anchor bolts (M6) (not supplied)
Wall-
mount
holes
Rope or
chain (not
supplied)
Wall-anchor
(not
supplied)
