Appendix
Specifications
• This model complies with the specifications below.
• Design and specifications are subject to change without notice.
• This model may not be compatible with features and/or specifications that may be added in the future.
Picture Tube 32 in. (800.1 mm) diagonal (Screen size is approximate.)
Television system NTSC standard
Channel coverage VHF: 2–13
UHF: 14–69
Cable TV: 4A, A-5–A-1, A-I,
J–W, W
+
1–W
+
84
Power source 120V AC, 60 Hz
Power consumption 130 W
Audio power 5.0 W + 5.0 W
Speaker type 1-13/16 in. x 3-7/8 in. (45.7 mm x 99.1 mm) x 2 pcs.
Video/Audio terminals S-VIDEO INPUT
Y-INPUT: 1V (p-p), 75 ohm, negative sync.
C-INPUT: 0.286V (p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT
VIDEO: 1V (p-p), 75 ohm, negative sync.
AUDIO: 150 mV (rms) (30% modulation equivalent, 47k ohm)
ColorStream
®
(component video) INPUT
Y : 1V (p-p), 75 ohm
PR : 0.7V (p-p), 75 ohm
PB : 0.7V (p-p), 75 ohm
VIDEO/AUDIO OUTPUT
VIDEO: 1V (p-p), 75 ohm, negative sync.
AUDIO: 150 mV (rms) (30% modulation equivalent, 47k ohm)
Dimensions Width : 29-9/16 in. (751 mm)
Height : 25-15/16 in. (658.5 mm)
Depth : 21-3/4 in. (552 mm)
Weight 114.7 Ibs. (52 kg)
Supplied accessories Remote control with two size “AAA” batteries
