MRF-300 BASE STATION
Step 7 - Test RF Address
Test that pressing a button
on the remote control
lights the STATUS LED of
the MRF-300.The STATUS
LED only lights when the
correct RF address is
received.
Step 8 - Adjust IR Line
Output Levels
Adjust each of the IR Line Output levels for best operation.
NOTE: TiVo, Replay TV, Satellite Receivers and Cable Boxes are all extremely
sensitive to IR overload or saturation. Put up the on screen guide and test the
navigation arrows. If operation is inconsistent or sluggish, LOWER the IR line
output.
If you still have sluggish operation, check that the remote control is set to a
particular LINE OUT, rather than ALL.When IR commands are sent to all the
flashers in a cabinet, you can have difficulty adjusting the IR Output.
Reprogram the remote control to send IR commands only via a specific (1-6)
Line Output, then readjust the IR Line Output level.
