RS-232↔RS-422 INTERFACE CONVERTER
5
1. Specifications
Speed — 64,000 bps, max.
Connectors — RS-232 port: DB25 female; RS-422 port: DB37 female
Indicators — 7 LEDs show status of RS-232 and RS-422 signals and indicate power ON.
RS-232 Port: DSR, CTS, DATA;
RS-422 Port: DSR, CTS, DATA
Controls — RS-232 port: DTE/DCE DIP shunts;
RS-422 port: DTE/DCE DIP shunts;
DIP switch to enable receiver termination
Environment — Storage Temperature: -4 to +158°F (-20 to +70°C);
Operating Temperature: 32 to 122°F (0 to 50°C)
Power — 115 VAC Supply: ±10%, 100 mA
230 VAC Supply: ±10%, 50 mA
Size — Standalone: 2.3"H x 8"W x 11.9"D (5.8 x 20.3 x 30.2 cm);
Rackmount: 1.2"H x 7.5"W x 11.4"D (3.1 x 19.1 x 29 cm)
Weight — Standalone: 2 lb. (1 kg);
Rackmount: 10 oz. (283.5 g)
