Installation instructions
11
DX-TVM112
STEP 6 - Mounting the TV to the wall plate
1 Place the TV brackets (B and C) into the slotted flanges of the wall plate (A).
2 Push the bottom of the TV toward the wall until the latch mechanism clicks into place.
B
A
C
and
HEAVY! You will need
assistance with this step.
Latched
