To verify that the product ground connects to the site AC power supply ground, follow these
steps:
1. Ensure that the site AC power supply circuit breakers serving the cabinet are set to OFF.
2. Ensure that the cabinet main circuit breaker is set to OFF.
3. Touch one test probe to the site AC power supply ground source.
4. Touch the other test probe to an unpainted metal surface of the cabinet.
NOTE: If the digital multimeter (DMM) leads can not reach from the junction box to the
cabinet, use a piece of wire connected to the ground terminal of the junction box.
5. Check for continuity indication of less than 0.1 ohm.
• If continuity is not found, check to ensure that the DMM test leads are making good
contact to unpainted metal and try again.
• If continuity is still not found, disconnect the cabinet site AC power immediately and
notify the customer of the probability of incorrectly wired AC power to the cabinet.
• If continuity is good, and connection of the cabinet to site AC power supply ground
(and not floating or connected to a phase) is verified, then check the voltage.
NOTE: For dual power sources, proceed to “Checking Voltage” (page 88) with special attention
to PDCA 0 ground pin to PDCA 1 ground pin voltage. Anything greater than 3 V is cause for
further investigation.
Installing and Verifying the PDCA
All systems are delivered with the appropriate cable plug for options 6 and 7 (Figure 3-25
(page 85)).
Check the voltages at the receptacle prior to plugging in the PDCA plug.
• To verify the proper wiring for a 4-wire PDCA, use a digital voltmeter (DVM) to measure
the voltage at the receptacle. Voltage must read 200–240 V ac phase-to-phase as measured
between the receptacle pins as follows: L1 to L2, L2 to L3, L1 to L3 (Figure 3-26 (page 85)).
• To verify the proper wiring for a 5-wire PDCA, use a DVM to measure the voltage at the
receptacle. Voltage must read 200–240 V ac phase-to-neutral as measured between the
receptacle pins as follows: L1 to N, L2 to N, L3 to N (Figure 3-27 (page 86)).
