AVDS - Expanding the AVDS System 11
5 Expanding the AVDS System
You can expand the AVDS system to 512 Remote units by having up to two levels
of Line Splitters. Each Line Splitter on level 1 can have eight Remote units or Line
Splitters connected to it. Each Line Splitter on level 2 can connect to eight Remote
units. (
Figure 10 illustrates the configuration diagram).
Figure 10 illustrates the expanded AVDS configuration without optional computers
connected to the Remote units. The connections are minus the Remote Video and
Audio cables.
