Video Recording
• Recording System: PAL / NTSC
• Compression formats: MPEG2
• Modes of Record Quality:
High Quality : HQ
Standard Play : SP
Standard Play Plus : SP+
Long Play : LP
Extended Play : EP
Super Long Play : SLP
Super Extended Play : SEP
• Recording enhancements:
Auto Chapter Marker Insertion, Divide Title,
Erase, Manual Chapter Marking, One Touch
Record
• Audio compression: Dolby Digital
Video Playback
• Disc Playback Media: CD, CD-R/CD-RW, DVD,
DVD-Video, DVD+R, DVD+RW, DVD-R,
DVD-RW, MP3-CD, Video CD, SVCD
• Compression formats: MPEG2, MPEG1, MPEG4,
DivX
• Video disc playback system: PAL, NTSC
Audio Playback
• Disc Playback Media: MP3-CD, CD, CD-R/
CD-RW
• Compression formats: Dolby Digital, DTS, MP3,
PCM,
• MP3 bit rates: 32 - 256 kbps
Still Picture Playback
• Disc Playback Media: Picture CD
• Picture compression format: JPEG
• Picture enhancement: Rotate, Zoom, Slideshow
TV systems
• Playback: PAL/NTSC
• Recording: PAL/NTSC
• Internal tuner: PAL
Video Performance
• D/A Converter 10 bit, 54 MHz
• A/D Converter 10 bit, 27 MHz
• Picture Enhancement: Progressive Scan
Audio Performance
• DA Converter 24 bit, 192 kHz
• AD Converter 24 bit, 96 kHz
• Signal / Noise (1kHz) 90 dB
• Dynamic range (1kHz) 80 dB
• Crosstalk (1kHz) 90 dB
Tuner/Reception/ Transmission
• Receive TV signal : PAL(This set does not
support NTSC)
• Aerial input: 75 ohm coaxial (IEC75)
Storage Media
• Recording :
– DVD+R, DVD+RW, DVD-R, DVD-RW,
• Hard Disk Capacity:
– DVDR 3425H : 160GB
– DVDR 3435H : 250GB
• HDD recording enhancements:
– Instant Replay, Time Shift Buffer
• Extra Hard Disk Technology:
– Pause Live TV, Simultaneous Record and
Playback, Direct Record to DVD
• HDD to DVD archiving: high speed (direct copy)
Connectivity
• Rear Connections
– S-video IN/OUT
– Video (CVBS) IN/OUT
– Analog audio Left/Right out
(only for DVDR3425H)
– Analog audio 5.1 out
(only for DVDR3435H)
– Antenna in
– TV out
– Digital audio out
DVDR3425H: COAXIAL.
DVDR3435H: COAXIAL, OPTICAL.
– Analog audio Left/Right in
– YPbPr video OUT
– YPbPr video IN (only for DVDR3435H)
*
Hint: This set can support progressive and
interleaved output but do not support progressive
input.
•
Front Connections
– i.LINK DV in (4 1394 4-pin)
– S-Video in
– Video (CVBS) in
– Analog audio left/right in
– USB in
Timer Recording
• Programmable events: 20
• Repeat modes: Once, Daily, Weekly, Mon-fri,
Mon-sat, Weekend.
• Enhancement: Manual Timer
Convenience
• Direct Record to optical disc
• Child Protection: Parental Control
Specications
Display panel symbols/ messages
Power
• Power Supply: 110V~240V, 50~60 Hz
• Power Consumption: 36 W
• Standby power consumption: < 5.0 W
Dimensions
• Set dimension (W x H x D) : 430 x 57 x 340 mm
• Set Weight : 4.4 kg
The following symbols/messages may
appear on your recorder display:
l
00:00
Multifunction display/ text line
– Title/track number
– Total/elapsed/remaining title/track time
– Disc/title name
– Additional information regarding the disc
– TV channel number or source of video
– Clock (This is displayed in Standby mode).
– TV program title
l
X TIMER
A timer recording has been programmed
or is active.
l
BLANK
No recordings on the disc.
l
EMPTY
No recordings in the hard disk drive.
l
UPDATE
Please wait until the blinking message
disappears. The disc is being formatted or
data is being written to it.
l
MENU
The system setup menu, disc menu, title
menu or timer menu display is on.
l
NO DISC
No disc has been inserted. If a disc has
been inserted, then it is possible that the
disc cannot be read.
