set flowcontrol [n]
enable/disable
Enable/Disable the flow control function to specific port [n] of GSW-2416SF.
set vlantag [n]
enable/disable
Enable/Disable the VLAN Tagging to specific egress port of GSW-2416SF.
set vlanaware [n]
enable/disable
Enable/D
isable VLAN-Aware function to specific port of GSW-2416SF.
set priority [n] [m] Allow to configure the priority setting of GSW-2416SF.
set pvid [n] [m] Assign PVID on each port of GSW-2416SF.
set vid [n] [m] Assign VLAN ID [m] to specific VLAN Group [n]
set IP xxx.xxx.xxx.xxx,
mmm. mmm, mmm, mmm,
ggg.ggg.ggg.ggg
Assign IP address, subnet mask, gateway of GSW-2416SF.
set pass [oldpass]
[newpass]
Change the default password of GSW-2416SF, the maximum length is 8
characters.
factory default Reset the GSW-2416SF to factory default mode.
reboot Reboot the GSW-2416SF.
logout Logout console interface of GSW-2416SF.
Table 4-1 Detail description of GSW-2416SF available commands
#Notice: Only accept command in lowercase letter under console interface.
4.4.2 Show command
From the main menu screen (see Figure 4-3), input “show” and press enter. The show command list screen in Figure 4-5
appears.
This s ist contains el
sho ase refer to chap
Figure 4-5 Show command list screen
how command l even items:
w port : Ple
ter 4.4.2.1.
sho : Please refer to cw static [n]
hapter 4.4.2.2.
show vlan : Please refer to chapter 4.4.2.3
.
sho refer to chapter
w ip : Please
4.4.2.4.
sho lease refer to chw version : P apter 4.4.2.5.
EM-GSW2416SFv1 - 15 -
