- 9 -
Figure 3-1 : Password Screen
The default user name and password is "root". After the password is entered you will
see the main menu screen.
Figure 3-2: The start up screen of MGSW-2402 Web Page
3.3 Home
The Home page displays the configuration of the MGSW-2402 Intelligent Switch.
System Name An administratively-assigned name of the managed unit
System Location The physical location of this managed unit
System Contact The contact person for this managed unit.
System Up Time The time last since the managed unit
IP Address The IP address of the managed unit
Subnet Mask The subnet mask of the managed unit
Default Gateway The default Gateway of the managed unit
MAC Address The MAC address of the managed unit
Console The RS232 Console setting of the managed unit
Firmware Version The firmware version of the managed unit
